Supermarket Shelves Plastic Label Extrusion Making Machine Plastic Price Tag Strip Production Line
جزئیات محصول
| قطر لوله: | 75-250 | قدرت اکسترودر: | 55 کیلو وات |
|---|---|---|---|
| رنگ: | سفارشی | لوله کشی: | لوله دوتایی |
| مواد اولیه: | پودر و مواد افزودنی پی وی سی | کاربرد: | لوله تأمین آب |
| ولتاژ: | 380 ولت 50 هرتز یا سفارشی | درجه اتوماتیک: | کاملاً اتمی |
| طرح: | پیچ دوقلو و بشکه | خدمات پس از فروش ارائه شده است: | مهندسان موجود برای ماشین آلات خدمات در خارج از کشور ، نصب میدانی ، راه اندازی و آموزش ، پشتیبانی آنل |
| ضمانت: | 18 ماه | اینور: | ابهام |
| رنگ: | قابل تنظیم | مواد اولیه: | پودر پی وی سی |
| موتور: | برند زیمنس | کنتاکتور: | زیمنس یا اشنایدر |
| پیچ و بشکه: | اکسترودر پیچ دوقلوی مخروطی | قطر پیچ: | 65/132 |
| کاربردی لوله: | منبع | بسته ها: | فیلم و جعبه |
| پرداخت: | T/T ، L/C ، Western Union | زمان تحویل: | 60 روز |
| برجسته کردن |
Plastic Price Tag Strip Production Line,Supermarket Shelves Label Extrusion Line |
||
توضیحات محصول
Supermarket Shelves Plastic Label Extrusion Making Machine Plastic Price Tag Strip Production Line
Short description
The PVC profile production line is widely used for producing various PVC profiles, such as PVC window&door profile, PVC ceiling panel, PVC trunking. With drawing sections of the PVC profile, tailed solutions and mould will be made.
Processing Process
The process flow of this line is PVC powder + additive - mixing-material feeder-twin screw extruder- mould and calibrator-vacuum forming table-haul-off machine-cutting machine-discharge rack.
This PVC profile extrusion line adopts conical twin screw extruder, which is suitable for both PVC powder and PVC granules. It has degassing system to ensure the excellent material plasticization. The high speed mould is available, and it can largely increase the productivity.
Application
Suitable for supermarkets,convenience stores,chain stores,wholesale markets for fruit and food placement labels.The products have many varieties,bright transparency not easy to break,durable and other characteristics.
Specifications
|
Model
|
LB180 | LB240 | LB300 | LB600 |
|
Max width of products(mm)
|
180 | 240 | 300 | 600 |
|
Screw Model
|
SJ55/110
|
SJ65/132
|
SJ65/132
|
SJ80/156
|
|
Motor power
|
22KW
|
37KW
|
37KW |
55KW
|
|
Cooling Water(m3/h)
|
5 | 7 | 7 | 10 |
|
Compressor(m3/h)
|
0.2 | 0.3 | 0.3 | 0.4 |
|
Total length(m)
|
18m | 22m | 22m | 25m |
